Skellet as element
element
Modular steel construction system
Detail of a Skellet joint
A skellet construction
1. Round tubes are structural the most efficient, but hard to connect.
2. Square profiles with second best structural properties are better, but the downside is that the thickening of the connectors gets in the way.
3. The cross-box Skellet profile combines the strenght of the square tube with space for all kinds of connecting pieces.
3rd reassembly of a Skellet system in GTB Lab Module
Samenvatting
Skellet can be dismantled down to the smallest component. Both the profiles and the connectors can then be reused in any project. The reusability also means that the profiles and connectors retain a higher residual value.
Details
Skellet is a construction system that can be used in a variety of applications. The system consists of two steel profiles and a range of connectors. The Skellet profile is a cross-box steel profile with recessed surfaces in which holes are punched every 25 mm. These holes create a grid that ensures a stable construction. Each connector is designed with the same holes and can therefore always be connected to the grid, which makes building with Skellet very accessible to any (do-it-yourself) builder. This hole pattern ensures dimensional consistency and flexibility, a key requirement for circular design.
The Skellet construction system consists only of bolted and riveted joints. These can be loosened without damaging the profile or the connectors. These profiles can then be perfectly reused in another project.
Ontwerp
Skellet
Producent
Skellet
Productielocatie
Kompellaan 11, Genk, Belgium
Materialen
Steel cold-rolled
Afmetingen
Length:
Width:
Height (or depth):
Thickness:
3 6250 mm
100 mm
100 mm
2 mm
Vorm
Cross box, perforated every 25 mm
Oppervlakteschade
No.
Schadelijke stoffen
Geen
Materiaalgeschiedenis
2019 - produced and assembled in Ridderkerk NL
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Gewicht:
Opgenomen CO2:
22,68 kg
35,15 kg CO2
Hergebruikpotentieel:
Terugwinningsopties:
0.7
Reuse by minor repair
Hergebruikt gewicht:
Hergebruikt CO2:
15,87 kg
24,61 ton CO2
Aantal elementen:
Aantal demontagestappen:
6
10
Resterende technische levenscyclus:
95 jaar
