Pilkington Insulight™ HeatComfort
element
Reversible heated glass
Installing the reused heated glass at GTB Lab.
Samenvatting
Heated windows made of insulating glass elements based on electrically conductive coating.
Details
By applying a voltage to the electrically conductive coating, the glass heats up, so when incorporated into an insulating glass unit, the heat flow can be directed into the living space. The two outer panes of the triple glass window contain reflective coatings reflecting the heat into the interior.
Tests in GTB Lab show a on the outside a maximum of 1 degree of temperature difference, while the inside rises to 45 degrees.
Waste during production was minimised by using the maximum production width of the glass (1180mm) as the grid size for the GTB Lab Module. In the subsequent transformation phase, no new material was used at all, but the glass was reused in its entirety.
Ontwerp
Pilkington
Producent
Pilkington Nederland BV
Productielocatie
De Hoeveler 25, Enschede, The Netherlands
Materialen
Glass
Afmetingen
Length:
Width:
Height (or depth):
Thickness:
3 100 mm
1 180 mm
52 mm
Vorm
Rectangular
Oppervlakteschade
2 out of 4 have a small crack in the outer pane.
Schadelijke stoffen
Geen
Materiaalgeschiedenis
2019 - produced by Pilkington and assembled in Ridderkerk NL
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
Gewicht:
Opgenomen CO2:
207,25 kg (56,7 kg/m2)
362,07 kg CO2 (94,6 kg CO2/m2)
Hergebruikpotentieel:
Terugwinningsopties:
0.8
Reuse by minor repair
Hergebruikt gewicht:
Hergebruikt CO2:
165,80 kg
289,66 kg CO2
Aantal elementen:
Aantal demontagestappen:
1
Resterende technische levenscyclus:
25 jaar
