Pilkington Sunplus™ BIPV
element
Reversible power generating glass
Connection points for the electric cables to the invertor.
Solar strips allow filtered sunlight to enter the building.
Samenvatting
Solar windows made of power generating insulating glass elements based on photovoltaic strips inside the triple glazing.
Details
Energy producing glazing is a solution for making homes and other buildings energy efficient. The strips generate energy, filter direct sunlight (reduce heat stress) and the triple glazing is the highest quality insulation. In addition it is an integrated part of the architecture and building façade.
Waste during production was minimised by using the maximum production width of the glass (1180mm) as the grid size for the GTB Lab Module. In the subsequent transformation phase, no new material was used at all, but the glass was reused in its entirety.
Ontwerp
Pilkington
Producent
Pilkington Nederland BV
Productielocatie
De Hoeveler 25, Enschede, The Netherlands
Materialen
Glass
Afmetingen
Length:
Width:
Height (or depth):
Thickness:
3 100 mm
1 180 mm
52 mm
Vorm
Rectangular
Oppervlakteschade
Schadelijke stoffen
Geen
Materiaalgeschiedenis
2019 - produced by Pilkington and assembled in Ridderkerk NL
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
Gewicht:
Opgenomen CO2:
207,25 kg (56,7 kg/m2)
362,07 kg CO2 (94,6 kg CO2/m2)
Hergebruikpotentieel:
Terugwinningsopties:
0.8
Reuse by minor repair
Hergebruikt gewicht:
Hergebruikt CO2:
165,80 kg
289,66 kg CO2
Aantal elementen:
Aantal demontagestappen:
1
Resterende technische levenscyclus:
25 jaar
