Jansen VISS Linea
element
Steel facade profile
Samenvatting
The Jansen VISS facade system, based on intermediaries and interlock connection, allows different subsystems to be assembled and disassembled independently by locking one element to two connecting parts.
Details
An intermediary connects the steel profiles to the load-bearing system, based on interlocking. Facade elements such as glazing are clamped to the mullion/transom structure using pins and clamping profiles. An aluminium cover profile is clicked on from the outside for finishing.
Ontwerp
4D Architects
Producent
Jansen AG
Productielocatie
Industriestrasse 34, Oberriet, Zwitserland
Materialen
Afmetingen
Length:
Width:
Height (or depth):
Thickness:
3 125 mm
50 mm
60 mm
2 mm
Vorm
T-shape tube
Oppervlakteschade
No.
Schadelijke stoffen
Geen
Materiaalgeschiedenis
2019 - produced by Jansen and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Gewicht:
Opgenomen CO2:
10,8 kg
16,7 kg CO2
Hergebruikpotentieel:
Terugwinningsopties:
0.9
Direct hergebruik
Hergebruikt gewicht:
Hergebruikt CO2:
9,7 kg
15,1 kg CO2
Aantal elementen:
Aantal demontagestappen:
4
Resterende technische levenscyclus:
95 jaar
