Jansen VISS Facade
component/systeem
Steel facade system
Intermediary connector.
Jansen VISS Linea mullion connected to Skellet with intermediary.
Samenvatting
The Jansen VISS facade system, based on intermediaries and interlock connection, allows different subsystems to be assembled and disassembled independently by locking one element to two connecting parts.
Details
An intermediary connects the steel profiles to the load-bearing system, based on interlocking. Facade elements such as glazing are clamped to the mullion/transom structure using pins and clamping profiles. An aluminium cover profile is clicked on from the outside for finishing.
Ontwerp
4D Architects
Producent
Jansen AG
Productielocatie
Industriestrasse 34, Oberriet, Zwitserland
Industrieconsortium
Jansen AG
Afmetingen
Lengte:
Breedte:
Hoogte (diepte):
Dikte:
Oppervlak:
Volume:
2x 4 900 mm
152 mm
3 125 mm
1,48 m2
4,64 m3
Schadelijke stoffen
Geen
Geschiedenis
2019 - produced by Jansen and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circulariteitsgegevens
Gewicht:
Opgenomen CO2:
1,91 ton (62,4 kg/m2)
4,00 ton CO2 (130,4 kg CO2/m2)
Hergebruikpotentieel:
Terugwinningsopties:
0.7
Reuse by minor repair
Hergebruikt gewicht:
Hergebruikte CO2:
1,34 ton (43,7 kg/m2)
2,80 ton CO2 (91,3 kg CO2/m2)
Aantal elementen:
Aantal demontagestappen:
62
Resterende Technische Levenscyclus:
95 jaar
