Jansen VISS Linea
element
Steel facade profile
Summary
The Jansen VISS facade system, based on intermediaries and interlock connection, allows different subsystems to be assembled and disassembled independently by locking one element to two connecting parts.
Details
An intermediary connects the steel profiles to the load-bearing system, based on interlocking. Facade elements such as glazing are clamped to the mullion/transom structure using pins and clamping profiles. An aluminium cover profile is clicked on from the outside for finishing.
Design
4D Architects
Manufacturer
Jansen AG
Manufacturing location
Industriestrasse 34, Oberriet, Zwitserland
Materials
Dimensions
Length:
Width:
Height (or depth):
Thickness:
3 125 mm
50 mm
60 mm
2 mm
Shape
T-shape tube
Surface damage
No.
Hazardous materials
None
Material history
2019 - produced by Jansen and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circularity data
Embodied mass:
Embodied carbon:
10,8 kg
16,7 kg CO2
Reuse Potential:
Recovery option
0.9
Direct reuse
Reused tonnage:
Reused carbon:
9,7 kg
15,1 kg CO2
No. of elements:
No. of disassembly steps:
4
Remaining Technical Life Cycle:
95 year
