GTB Lab Module
component/system
Multifunctional reversible module
3 transformations of GTB Lab without waste. The façade with door transforms into a terraced module, which in GTB Lab transforms into a light intermediate module.
Test of transformations: floor becomes roof, which becomes facade, which becomes terrace and again becomes facade with door, etc.
Summary
GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts.
Details
GTB Lab Circular Module project has been developed as a EU Horizon 2020 BAMB pilot with full reversibility in mind aiming at high reuse potential of all building parts. ","4 reversibility scenarios have been investigated and applied.
1. Reversibility at module level, including replicability of façade, roof, floor, e.g. using the façade cassettes to create a floor/terrace that has taken place during the modules, and extensibility of the module transformation.
2. Reversibility at component level, including reconfiguration of the floor, roof or facade cassette by transforming the door into a window or shelf.
3. Coordination of design and production dimensions to eliminate 98% of production waste.
4. 3D module replicability/transportation and module expandability.
Design
4D Architects
Manufacturer
Kloeckner Metals ODS NL
Manufacturing location
Keurmeesterstraat 4, 2984 BA Ridderkerk
Industry consortium
Kloeckner Metals ODS NL/Jansen, Pilkington NL, Ammanu LED-Intelligence, Jongen Bouwpartners, Rodeca BV, Adviesbureau Brekelmans, MJB Groep - Bouwregisseurs, ABT Ingenieurs in Bouwtechniek, TheNewMakers, Bluedeck, Moooz
Dimensions
Length:
Width:
Height (or depth):
Thickness:
Area:
Volume:
4 800 mm
4 800 mm
3 625 mm
23 m2
83,5 m3
Hazardous materials
None
History
2019 - produced and assembled in Ridderkerk NL
2019 - 3 transformations
2021 - reused in GTB Lab, Heerlen NL
Circularity data
Reversible BIM: the 3D color-coded model visualizes the reuse potential per element.
Embodied mass:
Embodied carbon:
14,34 ton
23,92 ton CO2
Reuse Potential:
Recovery option
0.8
Reuse by minor repair
Reused mass:
Reused carbon:
9,8 ton
16,5 ton CO2
No. of elements:
No. of disassembly steps:
353
10
Remaining Technical Life Cycle:
95 year
Circularity profile
Ratio of Reuse Potential after processing
Tonnage
Carbon
Material per recovery option
Ratio of Reuse Potential.
Tonnage
Carbon
Reused materials per function, and per recovery option
Tonnage
Carbon
Breakdown of materials
Tonnage
Carbon
Overview of materials per recovery option
Tonnage
Carbon
