Timber Roof
component/system
Reversible timber roof
Main beam before lifting it to its place.
Sliding beam over steel intermediairs.
Detail of connections.
Summary
The roof of the GTB Lab is the physical and architectural umbrella under which the experiments take place. It protects the activities and provides horizontal structural stability that allows for different kinds of transformations.
Details
The roof of the GTB Lab demonstrates how reversible core parts of a building allow for different transformations. The size provides flexibility for many unknown future developments.
The roof is made of laminated timber beams connected by steel joints. The diagonal pattern provides structural stability. The secondary beams are srewed on the main beams. The main beams and eaves are connected by steel plates and bolts for easy disassembly.
All elements were prefabricated and transported to site. The time on site was limited to a few days. The connection to the building also took place via intermediary steel joints between roof and tree columns/core steel frame.
Design
4D Architects
Manufacturer
De Groot Vroomshoop
Manufacturing location
De Groot Vroomshoop Groep B.V., Zwolsekanaal, Vroomshoop, Nederland
Industry consortium
De Groot Vroomshoop
Dimensions
Length:
Width:
Height (or depth):
Thickness:
Area:
Volume:
37 680 mm
11 280 mm
760 mm
425,0 m2
323,0 m3
Hazardous materials
None
History
2021 - produced in Enschede NL and placed at GTB Lab
Circularity data
Embodied mass:
Embodied carbon:
19,35 ton
24,91 ton CO2
Reuse Potential:
Recovery option
0.8
Reuse by minor repair
Reused mass:
Reused carbon:
No. of elements:
No. of disassembly steps:
240
Remaining Technical Life Cycle:
97 year
